ThaiFakopp ArborSonic 3D ; 10 sensors
- Our most popular product among arborists
- Detects the size and location of decayed or hollow regions
- Works fast: a measurement can be completed in 5-10 minutes
- Creates a 3D model of the trunk with multiple layers of measurement
- Customizable wind load modeling is included in the software
- Utilizes non-destructive technique using sound waves (no radiation)
- For trees with thick bark, 12 cm long nails are also available
Shipping calculated at checkout.
TECH SPECS
Measured time precision: ± 2 microseconds
Sensor: Low noise SD02 piezo sensor
Number of sensors: Variable from 8 up to 32
Amplifier box size: 127 x 58 x 25 mm
Power consumption: 240 mW
Power supply: Standard (rechargeable) 9V block battery
Continuous operation time*: Approximately 2 hours
Carrying case: Peli Case 1500EU
Total weight**: 6 kg
PC connection: RS232 over cable or Bluetooth
Data transmission time per sensor tap: Below one sec
Total measurement time of one tree***： 20 minutes
Operating temperature range： 0-40 °C
